Introduction Introduction
This bow-type drop cable consists of 2 color coded optical The typical GJY FCH/GJY CH self-supporting bow-type
fibers and offers an ideal solution for the smaller fiber Fiber(G.657.A2) drop optical cable consists of GJ FH/GJ H cable and an
counts that are needed in the final sections of an optical additional strength member (steel wire or stranded steel
network. Two parallel FRP/Steel Wire strength members wire). Steel Wire/KFRP
protect the optical fibers. The cable is completed with a
LSZH acket.
LSZH acket
Fiber(G.657.A2) MODULES
Order Information and Characteristics of Optical Cables
Tensile Strength Crush Resistance Bending Radius LSZH acket
Storage, operating
Cable Type Cable Size (mm) Weight (kg/km) Long/ShortTerm Long/ShortTerm Static/Dynamic
Temperature ( C)
(N) (N/100 mm) (mm)
Order Information and Characteristics of Optical Cables
NT-GJ FH-2B6a2 (2.0±0.1) (3.0±0.1) 7.5 40/80 500/1000 15/30 -20~+60
Tensile Strength Crush Resistance Bending Radius
NT-GJ H-2B6a2 (2.0±0.1) (3.0±0.1) 10.5 100/200 1000/2200 15/30 -20~+60 Storage, operating
Cable Type Cable Size (mm) Weight (kg/km) Long/ShortTerm Long/ShortTerm Static/Dynamic
Temperature ( C)
(N) (N/100 mm) (mm)
Characteristics NT-GJY FH-2B6a2 (2.0±0.1) (5.2±0.3) 18.9 300/600 1000/2200 15/30 -20~+60
Simple structure, light weight, high tensile strength. NT-GJY H-2B6a2 (2.0±0.1) (5.2±0.3) 21 300/600 1000/2200 15/30 -20~+60
Novel groove design, easily strip and splice, simpli ed installation and maintenance.
Low smoke, zero halogen and ame retardant sheath, environment-friendly, good safety. PATCH PANELS
Characteristics
G657 ber information Simple structure, light weight, high tensile strength.

Mode eld diameter (1310nm): 8.6 m±9.5 m. Novel groove design, easily strip and splice, simpli ed installation and maintenance.
Low smoke, zero halogen and ame retardant sheath, environment-friendly, good safety.

Cladding diameter: 125 m±0.7 m.

Coating diameter: 245 m±7 m.

Cut off wavelength of cabled ber ( cc): 1260 m. G657 ber information

Attenuation at 1310nm: 0.35dB/km.

Mode eld diameter (1310nm): 8.6 m±9.5 m.

Attenuation at 1550nm: 0.21dB/km.

Cladding diameter: 125 m±0.7 m.

Bending loss at 1550nm (100 turns, 30mm radius): 0.05dB.

Coating diameter: 245 m±7 m.
Dispersion in the range 1288 to 1339nm: 3.5ps/(nm km).
Cut off wavelength of cabled ber ( cc): 1260 m.
Dispersion at 1550nm: 18ps/(nm km).

Attenuation at 1310nm: 0.35dB/km.

Dispersion slope at zero dispersion wavelength: 0.092ps/(nm2 km).
Attenuation at 1550nm: 0.21dB/km. & XPON OPTICAL FIBER

Bending loss at 1550nm (100 turns, 30mm radius): 0.05dB.
Standards Dispersion in the range 1288 to 1339nm: 3.5ps/(nm km).

Comply with standard YD/T1997-2009 Dispersion at 1550nm: 18ps/(nm km).
Dispersion slope at zero dispersion wavelength: 0.092ps/(nm2 km).
Delivery Length
Standard Reel Length: 2000m Other lengths available on request. Standards
Comply with standard YD/T1997-2009
Delivery Length
Standard Reel Length: 2000m Other lengths available on request. CABINETS
