GPON GPON

GPON Cassette OLT GPON Cassette OLT FACE PLATE

Introduction
Nitrotel NTFG3304P NTFG3308P provides 4 8 GPON ports and 8 GE based-T 8GE SFP uplink ports to Model
Spec. NTFG3204P NTFG3308P
meet for the increasing demand on high-bandwidth from end user With the 1RU cassette design and
oyment and multifunctional
redundant 2 slots making it to be flexible deployment and multifunctional Gem port ty 4K/PON port 4K/PON port
TCONT ty 1K/PON port 1K/PON port
1RU cassette Broadban of PON port Uplink: 1.244G Downlink: 2.488G Uplink: 1.244G Downlink: 2.488G
1+1 power supply redundancy
4*GPON Ports Distance of Transmit 20KM 20KM
8*GE SFP Ports ONU/ONT remote management Support Support
8*GE based-T ports
2*SFP+ 10GE Ports ONU/ONT remote update Support Support MODULES
NTFG3304P Auto ONT ranging Support Support

Model
Spec. NTFG3204P NTFG3308P
1RU cassette
1+1 power supply redundancy MAC address entry 32K 32K
8xGPON Ports VLAN 4K 4K
8*GE SFP Ports
8*GE based-T ports VLAN manage VLAN Swap / VLAN Remark / VLAN Swap / VLAN Remark /
2*SFP+ 10GE Ports
VLAN Translate / Stack VLAN VLAN Translate / Stack VLAN
NTFG3308P
Spanning tree protocol STP, RSTP, MSTP STP, RSTP, MSTP
Link aggregation Static state and LACP Static state and LACP PATCH PANELS
Spec. Model NTFG3204P NTFG3308P Jumbo frame 9K 9K

PON chipsets Broadcom Broadcom

Switching capacity 102Gbps 102Gbps Spec. Model NTFG3204P NTFG3308P

Throughput rate 75.88Mpps 75.88Mpps Static Route Support Support
PON ports 4 8 RIP Support Support

Uplink ports 8*GE F +8*GE T 8*GE F +8*GE T OSPF Support Support

2*10GE SFP+ 2*10GE SFP+
VRRP Support Support
Console port 1 1

OoB manage ports 0 0 Model
Spec. NTFG3204P NTFG3308P & XPON OPTICAL FIBER
IGMP V1 / V2 / V3 V1 / V2 / V3
Spec. Model NTFG3204P NTFG3308P
IGMP Snooping Support Support
Size 440mm x 380mm x 44mm 440mm x 380mm x 44mm
IGMP Proxy Support Support
Weight 3kg 3kg
Multicast Group 1K 1K
dual power supply dual power supply
Power supply (AC or DC) redundancy (AC or DC) redundancy Multicast Protocol PIM-SM / PIM-DM / PIM-SSM PIM-SM / PIM-DM / PIM-SSM
Service Voltage AC: 100~240V DC:36V~75V AC: 100~240V DC:36V~75V
Consumption 70W 80W
Work/storage temperature -15 C 55 C / -40 C 70 C -15 C 55 C / -40 C 70 C
Humidity 10%~90% 10%~90% CABINETS
