NITROTEL PRODUCT INFORMATION    CABINETS                                                                                                                              CABINETS   NITROTEL PRODUCT INFORMATION        & PATCH CABLE  LAN CABLE



                      CABINET                                                                                                                                                                       CABINET



                      SPAR  SERIAL CABINETS                                                                                                            SPAR  SERIAL CABINETS







                      Main Part                                                                                                         Ordering Information
                         S/N      Speci cation    ty     Material     Surface Finish       Remark                                                             Width     Depth(D)     Capacity    Height(H)       CKD                        FACE PLATE
                                                                                                                                             Part Number.     (mm)        (mm)        ( U )       (mm)        packing parts
                          1         Rear door     1      SPCC t1.2    Powder coated    See front rear door type
                                                                                                                                            NT C  12U66                                12         536.6
                          2        Side panel     2      SPCC t1.0    Powder coated  1 Barrel lock/ 2 pieces sliding latches
                                                                                                                                            NT C  16U66                                16         714.4
                          3         19  rails     4      SPCC t1.4     zinc-plated
                                                                                                                                            NT C  20U66                                20         892.2
                          4      Support middle rails   6  SPCC t1.5   zinc-plated     2 C-type   4 Z-type rails
                                                                                                                                            NT C  22U66                                22         981.1
                          5         Roof panel    1      SPCC t1.2    Powder coated  Holes for 4 way ventilation   cable entry
                                                                                                                                            NT C  26U66                   600          26         1158.9
                          6          Frame        2      SPCC t1.5    Powder coated   Monoblock welded frames
                                                                                                                                            NT C  32U66                                32         1425.6
                          7     Cable management slot  2  SPCC t1.0   Powder coated  Only used for 800 width cabinet
                          8         Front door    1     SPCC t1.5/ 4mm   Powder coated  See front rear door type                            NT C  36U66                                36         1603.4
                                                        tempered glass
                                                                                                                                            NT C  42U66                                42         1870.1
                          9       Extension part  4      SPCC t1.5    Powder coated  2 pieces bottom / 2 pieces upper part                                                                                        3
                                                                                                                                            NT C  45U66                                45         2003.5
                         10        Bottom plate   1      SPCC t1.2    Powder coated
                                                                                                                                            NT C  47U66                                47         2092.4
                          11       Wheel plate    4      SPCC t1.5    Powder coated
                         12       heavy duty castor  4     ----           ----               ----                                           NT C  12U68                                12         536.6                                     MODULES
                                                                                                                                            NT C  16U68                                16         714.4
                        hardware kits with cabinet:
                                                                                                                                            NT C  20U68                                20         892.2
                          A      M12 ad ustable feet  4    Steel       Zinc-plated       Height:100MM
                                                                                                                                            NT C  22U68                                22         981.1
                          B          M6 screw  nuts  20    Steel       Zinc-plated                                                                             600
                                                                                                                                            NT C  26U68                                26         1158.9
                          C      uiet fan assembly kit   1  Steel     Powder coated   4 fans, 115V, 125 CFM/Min                                                           800
                                                                                                                                            NT C  32U68                                32         1425.6
                          D        Grounding kit  1 1     Copper          ----       4 ground wires, 1 ground bar
                                                                                                                                            NT C  36U68                                36         1603.4
                        Additional fan units available upon request.
                                                                                                                                            NT C  42U68                                42         1870.1
                                                                                                                                            NT C  45U68                                45         2003.5
                                                                                                                                                                                                                  3
                                                                                                                                            NT C  47U68                                47         2092.4
                                                                                                                                            NT C  12U61                                12         536.6
                                                                                                                                            NT C  16U61                                16         714.4
                                                                                                                                            NT C  26U61                                26         1158.9                                    PATCH PANELS
                                                                                                                                            NT C  32U61                                32         1425.6
                                                                                                                                                                          1000
                                                                                                                                            NT C  36U61                                36         1603.4
                                                                                                                                            NT C  42U61                                42         1870.1
                                                                                                                                            NT C  45U61                                45         2003.5
                                                                                                                                            NT C  47U61                                47         2092.4
                                                                Right-angled frame enables   Easy to connect and remove                                                                                           4
                                                                users to easily place the logo.   grounding kit                             NT C  26U88                                26         1158.9
                                                                                                                                            NT C  32U88                                32         1425.6
                                                               De nition of Code                                                            NT C  36U88                   800          36         1603.4
                                                                                                                                            NT C  42U88                                42         1870.1
                                                               NT C  U
                                                                                                                                            NT C  45U88                                45         2003.5
                                                                               Cabinet depth: (MM)  6 600 8 800 1 1000                      NT C  47U88                                47         2092.4
                                                                                                                    12 1200                                    800
                                                                                                                                            NT C  26U81                                26         1158.9                                   & XPON  OPTICAL FIBER
                                                                               Cabinet width: (mm): 6 600  8 800                            NT C  32U81                   1000         32         1425.6
                                                                                                                                            NT C  36U81                                36         1603.4
                                                                               Cabinet capacity ( U) 12, 16, 20, 22, 26, 32, 36, 42, 45, 47.                              1000
                                                                                                                                            NT C  42U81                                42         1870.1
                                                                               S: Server Cabinet                                            NT C  45U81                                45         2003.5
                                                                               80% perforated metal front door (type 0)
                                                                               63% perforated metal front door (type 1)                     NT C  47U81                                47         2092.4
                                                                               80% perforated metal double rear door (type 4)
                                                                               63% perforated metal double rear door(type 5)
                                                                               Solid metal rear door (type 2)
                                                                               N: Network Cabinet
                                                                               Tempered glass front door (type 3)
                                                                               Solid metal front door (type 2)
                                                                               Solid metal rear door (type 2)
                      *Special orders available upon request                                                                                                                                                                                CABINETS
