ALLMOUNT CABINET

SOHO Ca inet SOHO SIN LE SECTION

Feature FACE PLATE
Standard Disassembled and small packaging, easy to deliver and carry.
Comply with ANSI/EIA RS-310-D, Special design front and back frames are with good stability.
IEC60297-2, DIN41494, PART1; 16 screws are needed to assemble the whole enclosure. It will
DIN41494, PART7 take only 10 minutes to assemble the enclosure by one
person.
Material ide glass front door allows and excellent view of the interior
SPCC Cold Rolled Steel of the cabinet. Opening direction could be changed easily.
Thickness: 19 rails: 1.2mm, Cable entries are available on top, bottom and back of
others: 1.0mm enclosure, suitable for different places.
Maximum Loading capacity: 50kgs.
Color
RAL7035
RAL9004
Loading Capacity
Loading Capacity Definition of Code MODULES
Static loading: Up to 60 KG NTSOHO U500
Static loading: Up to 60 KG
Cabinet capacity(U): 6, 9, 12

Main Part
S/N Specification ty Material Surface Finish Remark
1 Top Cover 1 SPCC t1.0 Powder coated ----
2 Bottom Plate 1 SPCC t1.0 Powder coated ----
5MM toughed glass door/
3 Front door 1 ---- Small lock
SPCC t1.0
4 19 rails 2 SPCC t1.5 Powder coated ----
5 Side Panels 2 SPCC t1.0 Powder coated ---- PATCH PANELS
Specification
Model N o. RU idth (mm) Depth(D)(mm) Height(H)(mm) Static Loading Capacity (kg)
NTSOHO6U500 6 600 450 370 40
NTSOHO9U500 9 600 450 500 45
NTSOHO12U500 12 600 450 635 50

May Installs The Fitting & XPON OPTICAL FIBER

Cooling fan Blank filler panel Shelves Cable management

M6 Screws nuts Grounding kit PDUs CABINETS
